Square WebPay

This page discusses Square WebPay, the currently supported interface to Square.

There was an older Square module, based on the Square Payments Form library, which was built in to Zen Cart from 1.5.5 to 1.5.8. However, Square has deprecated this library, so the older module no longer works. The Square Payments Form documentation is maintained for historical purposes.

Square WebPay

• For PHP 7, the Square WebPay is an open source module available in the Plugins library as Square Web Payments API plugin.
• For PHP 8 and above, Square WebPay is a commercial extension which should be purchased from the developer.

• The top one (“Square”) is the old deprecated Square module.
• The bottom (“Square WebPay”) one is the new Square module.

Requirements

1. You must be using SSL on your website
2. You will need a Square account, already validated and connected with your bank. You may create a Square merchant account here.

Please note: do NOT remove the old Square files from your Zen Cart installation.

Installing Square Web Payments - first time

1. If you are a developer, ask your client to turn off 2FA on Square momentarily so you can login and do this work; they can turn it back on when you’re done.
2. Install the Square Web Payments module files. Then to go to Admin > Modules > Payments > Square WebPay, and click Install.
3. Double check - did you just install the module “Square WebPay”? If you’re on the module “Square,” it will look very similar but won’t work.
4. Login at https://connect.squareup.com/apps to view the apps you’ve connected to your account.
5. Click + to create a New Application for your Zen Cart store. Give it a name, such as “WebPay”. You cannot delete the app or change its name once it is created, so choose carefully. If it’s for a test installation of your site with a different URL, call it WebPay-Test or something like that.
6. Ensure you have selected the correct API version. See Square API Version.
   • Version 1.2.0 of Square Web Payments requires API Version 2024-02-22.
   • Version 1.0.1 of Square Web Payments requires API Version 2022-02-16.
7. Click on the application icon that was just created (named “WebPay” or whatever name you used).
8. The environment will be Sandbox by default. Click “Production”.
9. Copy and Paste the Production Application ID into your Square WebPay configuration Application ID field in Zen Cart admin.
10. Click on the OAuth tab. In the “Redirect URL” field, enter https://YOURSTORE.com/squareWebPay_handler.php and click Save at the bottom. (Ensure the URL you enter points to the correct directory or subdirectory on your server.)
11. Now click Show on the Production Application secret field. Copy and Paste the secret into your Square WebPay configuration Application Secret (OAuth) field in Zen Cart admin.
12. In your Zen Cart admin, do the following:
    • Click Update to save the new Square WebPay config values.
    • Click the green button in the Zen Cart admin sidebar that says “Click here to login and Authorize your account.” If everything is correct, the Sort Order LED for Square WebPay will go green.
    • Click the Edit button one more time. This will fill in the Location ID field. Click Update.
13. If this isn’t working, check again to be sure you are editing the “Square WebPay” module not the old “Square” module - it’s easy to get the two mixed up.

Once you have installed and successfully tested Square Webpay, you will want to create a cron job to refresh the Square token.

Updating Square Web Payments

1. Follow the guidance provided by the developer.
2. You may need to update your app to change the API version. See Square API Version.

Handling Refunds, Captures, Voids

Refunds

When viewing a transaction in your store Admin, if it was paid using Square within the last 120 days, you will be shown the option to Refund some or all of the payment. Simply enter the amount you wish to refund. Then check the box to confirm, and click Submit. You will see a status message confirming the refund has been issued.

NOTE: You SHOULD do all refunds via your store Admin. While you might be able to start a refund from your Square Dashboard, that will NOT automatically update your orders in Zen Cart to show the change in status. But if you do the refund from within your Zen Cart Admin, the refund will show in both places, as well as in the customer’s order-status-history, which is a more friendly experience for them.

Captures

If you’ve configured the module to “authorize only” instead of automatically capturing each “purchase”, then you will also see an option to Capture the previously-authorized transaction. CAPTURES MUST BE DONE WITHIN 6 DAYS, or they will be voided automatically, releasing the hold on those funds for the customer.

NOTE: Captures can ONLY be done via your store Admin. You will not see uncaptured (authorize-only) transactions in your Square Dashboard.

Voids

If you’ve configured the module to “authorize only”, then you will see a Void option. This can be used to cancel an Authorization and release the “hold” on those funds back to the customer.

NOTE: Voids can ONLY be done via your store Admin. You will not see authorize-only transactions in your Square Dashboard.

Reinstalling Square Web Payments

If your access token goes bad, you can get into a state where you have to delete and reinstall Square. Here’s what you need to do to configure the module once you have reinstalled it:

1. Login at https://connect.squareup.com/apps to view the apps you’ve connected to your account.
2. Click on the application icon that you created (probably named “WebPay” or whatever name you used).
3. Copy and Paste the Production Application ID into your Square WebPay configuration Application ID field in Zen Cart admin.
4. Click on the OAuth tab.
5. Now click Show on the Production Application secret field. Copy and Paste the secret into your Square WebPay configuration Application Secret (OAuth) in Zen Cart admin.
6. In your Zen Cart admin, do the following:

• Click Update to save the new Square WebPay config values.
• Click the green button in the Zen Cart admin sidebar that says “Click here to login and Authorize your account.” If everything is correct, the Sort Order LED for Square WebPay will go green.
• Click the Edit button one more time. This will fill in the Location ID field. Click Update.

Upgrading to Square Web Payments from Square Payments Form

1. Go to Admin > Modules > Payment > Square, click Edit, and set Enable Square Module to false, then click Update.
2. Login at https://connect.squareup.com/apps. Note that you will need to pick a new name from your existing Square app . Unfortunately you cannot rename apps.
3. Use the Installation instructions above.
4. Once you are certain Square Web Payments is working, Go to Admin > Modules > Payment > Square and click Remove.

Square Errors

If you get an error from Square (in particular, “The provided OAuth access token has expired”), see Square Error Messages.
